Description
Chapter 1 PRODUCT DESCRIPTION
1.1 Product Description ………………………………………………………………………………… 11
1.2 Basic Specifications ………………………………………………………………………………… 12
1.2.1 Basic Specifications ………………………………………………………………………… 12
1.2.2 Electric Specifications …………………………………………………………………….. 13
1.2.3 Ink Specifications …………………………………………………………………………… 13
1.3 Printing Specifications …………………………………………………………………………….. 14
1.3.1 Paper Feed Specifications ……………………………………………………………….. 14
1.3.2 Paper Specification …………………………………………………………………………. 14
1.3.3 Designated Paper …………………………………………………………………………… 16
1.3.4 Borderless Printing Specification …………………………………………………….. 18
1.4 Hardware Specifications ………………………………………………………………………….. 19
1.4.1 Dimensions and Weight …………………………………………………………………… 19
1.4.2 Installation Room Requirement ………………………………………………………… 19
1.4.3 Part Names …………………………………………………………………………………….. 20
1.5 Control Panel ………………………………………………………………………………………….. 22
1.5.1 Menu Mode Settings ………………………………………………………………………… 25
1.5.2 Serviceman Mode ……………………………………………………………………………. 36
Chapter 2 OPERATING PRINCIPLES
2.1 Main Body ………………………………………………………………………………………………. 39
2.1.1 Housing …………………………………………………………………………………………… 39
2.1.2 Electric Circuit Components ……………………………………………………………… 40
2.1.3 Carriage Mechanism ………………………………………………………………………… 41
2.1.4 APG Mechanism ………………………………………………………………………………. 42
2.1.5 Paper Feed Mechanism …………………………………………………………………….. 43
2.1.6 Ink System ………………………………………………………………………………………. 44
2.2 Options …………………………………………………………………………………………………… 47
2.2.1 Auto Take-up Reel …………………………………………………………………………….. 47
2.2.2 SpectroProofer …………………………………………………………………………………. 48
Chapter 3 TROUBLE SHOOTING
3.1 Overview …………………………………………………………………………………………………. 50
3.1.1 Preliminary Check …………………………………………………………………………….. 50
3.1.2 Troubleshooting Procedure ……………………………………………………………….. 51
3.1.3 Procedure after troubleshooting ………………………………………………………… 51
3.2 Remedies for Maintenance Requests ………………………………………………………… 52
3.3 Remedies for Service Call Error ……………………………………………………………….. 54
3.4 Remedies for Print Quality Troubles …………………………………………………………. 78
3.4.1 Remedies for Print Quality Troubles ………………………………………………….. 78
3.5 Problems on SpectroProofer ……………………………………………………………………… 81
3.6 Remedies for Error Messages related to SpectroProofer/Auto Take-up Reel .. 84
3.7 Trouble on Service Program ……………………………………………………………………… 89
3.8 Trouble on NVRAM Viewer ………………………………………………………………………. 90
Chapter 4 DISASSEMBLY & ASSEMBLY
4.1 Overview …………………………………………………………………………………………………. 92
4.1.1 Precautions ………………………………………………………………………………………. 92
4.1.2 Orientation Definition ………………………………………………………………………. 94
4.1.3 Recommended Tools ………………………………………………………………………… 95
4.1.4 Cautions when replacing the Main Board Assy/Power Supply Board Assy 96
4.2 Parts Diagram ………………………………………………………………………………………….. 97
4.3 Disassembly Flowchart …………………………………………………………………………… 104
4.4 Disassembly and Assembly Procedure ……………………………………………………. 110
4.4.1 Special operation for servicing ………………………………………………………….. 110
4.4.2 Housing ……………………………………………………………………………………………. 112
4.4.3 Electric Circuit Components …………………………………………………………….. 137
4.4.4 Carriage Mechanism ………………………………………………………………………… 146
4.4.5 Paper Feed Mechanism …………………………………………………………………….. 169
4.4.6 Ink System Mechanism …………………………………………………………………….. 174
4.4.7 Auto Take-up Reel …………………………………………………………………………….. 179
